For equipment utilized in harsh environments including wide temperature ranges or air characteristics with elevated moisture and salt content, APC offers a range of UPS solutions for industrial control applications including communication accessories for dry contact I/O, Modbus and network management. During a power event, whether the requirement is safe shutdown or maintaining data integrity, the APC solution provides reliable protection.
-
25.26 lbs
-
Communications & Management
Interface Ports: DB-9 RS-232, SmartSlot Available
SmartSlot Interface Quantity: (1)
Control panel: LED status display with load and battery bar-graphs and On Line, On Battery, Replace Battery, and Overload Indicators
Audible Alarm: Alarm when on battery, distinctive low battery alarm, overload continuous tone alarm
Emergency Power Off (EPO): Yes
Conformance
Regulatory Approvals: UL Recognized
RoHS: Compliant
REACH: Contains No SVHCs -
# Ports: 1Communication Interface: Serial (RS-232)Connector: Hardwire 3-wire (1PH + N + G)Connector: Power Hard Wire 3-wire (1PH + N + G)
-
UPS, Smart UPS signalling RS-232 cable, documentation
-
Attributes: Line interactiveColor: BlackEnclosure Type: InternalForm Factor: DIN rail mountableManufacturer Product Line: APC Smart-UPSWarranty Period: 2 yearsWeight Taxonomy: 25.31lbs
-
5.8"h x 14.25"w x 6.7"d
-
Output Connections: (1) Hard Wire 3-wire (H + N + G)
Input Connections: Hard Wire 3-wire (1PH + N + G) -
Battery Run Time (max): 8minPower Capacity (VA): 500VAPower Provided: 325Power Provided: 325WSurge Suppression: StandardSurge Suppression: YesVoltage Provided: 120VVoltage Provided: AC 120V
-
Output
Output Power Capacity: 325W/500VA
Max Configurable Power: 325W/500VA
Nominal Output Voltage: 120V
Efficiency at Full Load: 94.0%
Output Voltage Distortion: Less than 5%
Output Frequency (sync to mains): 47-53Hz for 50Hz nominal, 57-63Hz for 60Hz nominal
Topology: Line Interactive
Waveform Type: Sine wave
Input
Nominal Input Voltage: 120V
Input Frequency: 50/60Hz +/- 3Hz (auto sensing)
Input voltage range for main operations: 82-144V
Input voltage adjustable range for mains operation: 75-154V
Batteries & Runtime
Battery Type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte, leakproof
Included Battery Modules: (1)
Available Battery Module Slots: (1)
Typical recharge time: 2 hours
Replacement Battery: APCRBC136
RBC Quantity: (1)
Runtime, full load: 8 minutes (325W)
Runtime, half load: 24.5 minutes (162W)
Surge Protection and Filtering
Surge energy rating: 540 Joules
Filtering: Full time multi-pole noise filtering, 0.3% IEEE surge let-through, zero clamping response time, meets UL 1449. -
This product has a limited return policy. For defective returns, technical issues and support please contact APC directly at 800-555-2725. Defective units should be replaced through APC directly. Visit http://www.apc.com/us/en/support/contact-us for APC warranty details and contact information.
-
20.9 lbs
-
Compliant Standards: REACHCompliant Standards: RoHSCompliant Standards: ULCompliant Standards: UL 1449
-
