Tripp Lite PDU Switched ATS 120V 20A 5-15 20R (16) Outlet L5-20P Horizontal 1U RM

The Tripp Lite 120V 20A Metered PDU with Automatic Transfer Switching (ATS) is an (16) outlet PDU with a digital display to indicate total PDU current usage. Outlets are sequentially turned on at 250 millisecond intervals when the PDU is first energized from an unpowered state to prevent inrush-related equipment interaction on startup. An installed web/network monitoring card enables remote power monitoring and control. The unit remotely displays the status of input power, load capacity, and outlet power condition via a secure network or web browser interface. The unit can be mounted as a 1U rackmount installation in 2 or 4-post racks.

Individual outlet control will power on, off, or cycle AC output to regain control of locked-up servers and other network devices. The load ramping and shedding feature gives you automatic power management in any type of network configuration and supports notification and logging of input power status, event notification, output power and PDU loading conditions.

Included are (16) NEMA 5-15/20R outlets and (2) 12ft. L5-20P power cords (one attached) for utilizing the auto-transfer switch (ATS) option. The integrated ATS is available for use when two separately derived input power sources are available. The attached power cord serves as the primary AC input cable, while the included detachable power cord serves as the optional-use secondary AC input connection. The PDU system passes the primary input power through to connected equipment whenever line voltage and frequency levels are normal. If the primary input source goes outside of these tolerances or fails altogether, the ATS will automatically switch all PDU output to the secondary line sourced input power (when available) to maintain continuous operation of connected loads without reboots or service interruptions.
