In Stock
- Ships in 1-2 Business Days
Power Distribution Unit for Network Applications
Add to Cart
Messages
Loading
-
:
Quick View
Getting Details
This Tripp Lite Basic Power Distribution Unit gives you the ability to power multiple servers and vital networking hardware from a single input power source. Switch-free unfiltered electrical pass-through reliably distributes UPS or generator power to critical equipment in rack enclosures, network closets and more. Tooless mounting enables simple installation in button-mount compatible racks and the included mounting brackets support vertical installation in standard 2 and 4 post racks or other surfaces, such as under-counter or wallmount configurations. the plug retention brackets keep vital equipment plugged in and continuously powered.
-
8.00 lbs
-
# Ports: 38Connector: Power IEC 320 EN 60320 C13 (F)Connector: Power IEC 320 EN 60320 C19 (F)Connector: Power NEMA L6-20 (M)Connector: Power NEMA L6-30Connector: Power NEMA L6-30P
-
PDU, (2) plug retention brackets, mounting brackets, installation hardware, documentation
-
Color: BlackForm Factor: 0U RackmountForm Factor: Rack-mountableWarranty Period: 5 yearsWeight Taxonomy: 7.94lbsWeight Taxonomy: 8lbs
-
63.75"h x 2.25"w x 3.75"d
-
(6) IEC 320-C19 outlets
(32) IEC 320-C13 outlets
(1) NEMA L6-30P input cord, 10ft. -
Power Provided: 5.5kWPower Provided: 5.8kWVoltage Provided: 208VVoltage Provided: 240VVoltage Provided: AC 208 - 230VVoltage Provided: AC 208/240V
-
Voltage compatibility: 208/240VAC
Frequency compatibility: 50/60Hz
OUTPUT
Output nominal voltage: 208/240VAC
Overload protection: Outlets are arranged in two separately breakered load banks. The top 15A breaker covers outlets on the upper half, the bottom 15A breaker covers outlets on the lower half of the PDU. Each breakered bank covers (16) C13 and (3) C19 outlets.
INPUT
Maximum input amps: 30A maximum (Agency de-rated to 24A)
Recommended electrical service: 208/240VAC, 30A -
This product is subject to our return policy. Please see our complete return policy for details.
-
13 lbs
-
Compliant Standards: CAN/CSA-C22.2 No. 62368-1Compliant Standards: NOMCompliant Standards: RoHSCompliant Standards: UL 60950-1Compliant Standards: UL 62368-1
-
