- PCI-Express 4.0 x16
- 100Gbps Transfer Rate
- Gigabit Ethernet Protocol(s)
- IEEE 1588 Compliant
Driven by the growing need for higher server bandwidth and storage capacity to support new and emerging applications (Machine Learning, HPC, Multi-node containers, NVMe, Web 2.0, NVMe storage disaggregation, HCI), enterprises, telcos and cloud providers are modernizing their data centers by adopting latest networking technologies, such as server virtualization and NVMe-oF. The resulting expansion in data volumes increases server-to-server traffic and CPU loads for networking tasks.
With its market-leading hardware acceleration technologies, the ThinkSystem Broadcom 57508 100GbE adapters address these performance and service demands of mega-scale data center networks with high throughput and advanced flow processing. Features such as TruFlow increase VM density up to 50%, freeing more CPU cycles for additional virtual machines. On-chip tunneling protocol processing for Geneve, VXLAN, and NVGRE provides up to a 5X throughput increase while lowering CPU utilization up to 90 percent compared to software-only solutions.
With its market-leading hardware acceleration technologies, the ThinkSystem Broadcom 57508 100GbE adapters address these performance and service demands of mega-scale data center networks with high throughput and advanced flow processing. Features such as TruFlow increase VM density up to 50%, freeing more CPU cycles for additional virtual machines. On-chip tunneling protocol processing for Geneve, VXLAN, and NVGRE provides up to a 5X throughput increase while lowering CPU utilization up to 90 percent compared to software-only solutions.
-
2x 100GbE network connectivity for high availability features eliminating throughput bottlenecks for data-intensive applications
Industry’s best performing and longest-reach 50G PAM-4 / 25G NRZ SerDes dramatically lowering TCO by reducing cable costs by 50% and doubling port density
Third generation Broadcom TruFlow engine for intelligent flow processing to increase server VM density and accelerate vSwitch processing of traffic flows with data path Acceleration. TruFlow enables efficient network flow processing, increases Virtual Machine density by offloading the server CPU to improve application performance.
RoCE (RDMA over Converged Ethernet), allows Remote Direct Memory Access (RDMA) traffic to be communicated over Converged Ethernet using DCB. GPU Compute over RoCE enables scalable GPU clusters up to hundreds of nodes using Ethernet for HPC, AI, and ML applications.
Broadcom’s Smart Congestion Control provides consistent and predictable performance for real world workloads plus scaling for heavily loaded network traffic making it ideal for clients looking for deterministic low latency.
Broadcom adapters are the industry’s most secure Ethernet controller solution, leveraging Broadcom’s BroadSAFE technology to provide unparalleled platform security via Silicon Root of Trust (RoT). Broadcom is the first Ethernet Adapter vendor to store authentication key and code in silicon to protect clients from maliciously modified firmware.
Broadcom’s TruManage enhances server manageability, network management, and security for data center deployments. TruManage supports widely deployed management standards including DMTF NC-SI, MCTP, PLDM, and SPDM specifications.
Support for SR-IOV which bypasses the hypervisor, reducing the latency by removing data copies and context switches between VM address space and hypervisor address space, when transmitting or receiving data over the network. The implementation supports 802.1Qbg Edge Virtual Bridging (EVB).
Support for Data Center Bridging (DCB), including IEEE 802.1Qbb Priority based Flow Control (PFC) and 802.1Qaz Enhanced Transmission Selection (ETS). DCB technology allows the device to provide lossless data delivery, prioritize low latency traffic, and share bandwidth among data center physical links.
In-band Network Telemetry features provide end-to-end real-time monitoring capability, enabling data center operators to fine tune their networks for maximum performance. -
Connectivity Technology: WiredSlot Type: PCI Express 4.0 x16Slot Type: PCI-Express 4.0 x16
-
adapter, documentation
-
Form Factor: Plug-in cardWarranty Period: 1-year warranty
-
Networking Type: Network adapter
-
Data Transfer Rate: 100Gbps
-
(2) QSFP56
-
Networking Protocol: Gigabit EthernetNetworking Protocol: IEEE 802.1QauNetworking Protocol: IEEE 802.1QazNetworking Protocol: IEEE 802.1QbbTransport Protocol: SMBTransport Protocol: TCP/IPTransport Protocol: UDP/IP
-
10 lbs
-
Compliant Standards: CNS 14336 Class BCompliant Standards: CSA 22.2 No. 950Compliant Standards: CTUVusCompliant Standards: EN 55022:2010+AC:2011 Class BCompliant Standards: EN 60950-1Compliant Standards: EN55024 Class BCompliant Standards: FCC CFR47 Part 15 B Class BCompliant Standards: ICES-003Compliant Standards: ICES-003 Class BCompliant Standards: IEEE 1588Compliant Standards: KN24Compliant Standards: UL 1977Compliant Standards: UL 60950-1Compliant Standards: UL 796Compliant Standards: UL 94Compliant Standards: VCCI - V-3/2014.04
-
OS Required: Microsoft Windows Server 2016OS Required: Microsoft Windows Server 2019OS Required: Red Hat Enterprise Linux 7.8OS Required: Red Hat Enterprise Linux 7.9OS Required: Red Hat Enterprise Linux 8.2OS Required: Red Hat Enterprise Linux 8.3OS Required: SuSE Linux Enterprise Server 12 SP5OS Required: SuSE Linux Enterprise Server 12 SP5 with XenOS Required: SuSE Linux Enterprise Server 15 SP1OS Required: SuSE Linux Enterprise Server 15 SP1 with XenOS Required: SuSE Linux Enterprise Server 15 SP2OS Required: SuSE Linux Enterprise Server 15 SP2 with XenOS Required: VMware vSphere Hypervisor 6.7 (ESXi) Update 3OS Required: VMware vSphere Hypervisor 7.0 (ESXi)OS Required: VMware vSphere Hypervisor 7.0 (ESXi) Update 1OS Required: VMware vSphere Hypervisor 7.0 (ESXi) Update 2
-
43201404
