The Cisco UCS B200 M4 blade server delivers record performance, expandability, and configurability for workloads ranging from web infrastructure to distributed databases. In addition, Cisco UCS has the architectural advantage of not having to power and cool switches in each blade chassis. Having a larger power budget available for blades allows Cisco to design uncompromised expandability and capabilities in its blade servers.
-
9.50 lbs
-
Blade server, (2) CPU heatsinks, (2) blanking panels, (12) DIMM blanks, documentation
-
EPEAT Compliant: YesePEAT Level: EPEAT Bronze
-
Chassis Form Factor: BladeColor: GrayForm Factor: DIMM 288-pinPrinter Type: NoneSystem Type: ServerWarranty Period: 3 yearsWeight Taxonomy: 9.5lbs
-
Cache Memory (installed): 22MBFlash Memory Form Factor: SD Memory CardMemory Attributes: Load-Reduced DIMM (LRDIMM)Memory Attributes: Through-silicon via DIMMs (TSV DIMMs)Memory Rating: PC4-21300RAM (installed): 192GBRAM (max): 3072GBRAM Technology: DDR4 SDRAM
-
192GB (6x32GB) 2666MHz ECC LRDIMM DDR4 SDRAM, upgradeable to 3072GB.
There are twenty-four 288-pin DIMM slots. Six slots are occupied by removable 32GB modules; the other slots are open.
Video memory: integrated Matrox G200e graphics -
There is no operating system pre-installed.
-
OS Provided: No operating systemOS Provided: No Operating System Installed
-
CD/DVD Type: No Optical DriveCD/DVD Type: None
-
2.0"h x 8.0"w x 24.4"d
-
Expansion slots:
(2) Expansion slots
(2) SD card slots
(2) M.2
Expansion bays:
(2) 2.5" hot-swap bays
I/O:
(1) KVM
(1) USB 3.0 (internal)
Networking controller:
Cisco UCS Virtual Interface Card 1340 -
# Processors Installed: 2# Processors Supported: 2Data Bus Speed: 2666MHzNumber of Cores: 16-coreProcessor Features: Intel Turbo Boost TechnologyProcessor Manufacturer: IntelProcessor Model Number: 6130Processor Speed: 2.1GHzProcessor Speed (Boosted): 3.7GHzProcessor Type: Xeon GoldProcessor Upgradability: Upgradable
-
Networking Protocol: 40Gb Fibre Channel over Ethernet (FCoE)
-
Due to manufacturer restrictions, all sales on this item are final.
-
1 lbs
-
Compliant Standards: ACPI 4.0Compliant Standards: EPEAT Bronze
-
Hard Drive Capacity: 0GBHard Drive Type: Hot-swapHard Drive Type: NoneStorage Controller Type: SATA/SAS
-
43211512
-
Display Technology: None.Video Card: Matrox G200eVideo RAM (installed): 8MB
