Cisco UCS SP B200 M5 Advanced 1 Blade (2x)Xeon 12C Gold 5118 2.3GHz 192GB 2x2.5" HS bays 10GbFCoE NoOS
-
Temporarily Out-of-Stock
- Call for next available delivery
Ordering Information
$7,898.08
Add to Cart
Messages
Loading
-
:
Quick View
Getting Details
The Cisco UCS B200 M4 blade server delivers record performance, expandability, and configurability for workloads ranging from web infrastructure to distributed databases. In addition, Cisco UCS has the architectural advantage of not having to power and cool switches in each blade chassis. Having a larger power budget available for blades allows Cisco to design uncompromised expandability and capabilities in its blade servers.
-
9.50 lbs
-
Blade server, (2) CPU heatsinks, (2) blanking panels, (12) DIMM blanks, documentation
-
EPEAT Compliant: YesePEAT Level: EPEAT Bronze
-
Chassis Form Factor: BladeColor: GrayForm Factor: DIMM 288-pinPrinter Type: NoneSystem Type: ServerWeight Taxonomy: 9.5lbs
-
Cache Memory (installed): 16MBFlash Memory Form Factor: SD Memory CardMemory Attributes: Load-Reduced DIMM (LRDIMM)Memory Attributes: Through-silicon via DIMMs (TSV DIMMs)Memory Rating: PC4-21300RAM (installed): 192GBRAM (max): 768GBRAM Technology: DDR4 SDRAM
-
192GB (12x16GB) 2666MHz* ECC LRDIMM DDR4 SDRAM, upgradeable to 3072GB.
There are twenty-four 288-pin DIMM slots. Twelve slots are occupied by removable 16GB modules; the other slots are open.
*Memory will operate at 2400MHz due to processor limitations
Video memory: integrated Matrox G200e graphics -
There is no operating system pre-installed.
-
OS Provided: No operating systemOS Provided: No Operating System Installed
-
CD/DVD Type: No Optical DriveCD/DVD Type: None
-
2.0"h x 8.0"w x 24.4"d
-
Expansion slots:
(2) Expansion slots
(2) SD card slots
(2) M.2
Expansion bays:
(2) 2.5" hot-swap bays
I/O:
(1) KVM
(1) USB 3.0 (internal)
Networking controller:
Cisco UCS Virtual Interface Card 1340 -
# Processors Installed: 2# Processors Supported: 2Data Bus Speed: 2400MHzNumber of Cores: 12-coreProcessor Features: Intel Turbo Boost TechnologyProcessor Manufacturer: IntelProcessor Model Number: 5118Processor Speed: 2.3GHzProcessor Speed (Boosted): 3.2GHzProcessor Type: Xeon GoldProcessor Upgradability: Upgradable
-
Networking Protocol: 10Gb Fibre Channel over Ethernet (FCoE)Networking Protocol: 40Gb Fibre Channel over Ethernet (FCoE)
-
Due to manufacturer restrictions, all sales on this item are final.
-
1 lbs
-
Compliant Standards: ACPI 4.0Compliant Standards: EPEAT Bronze
-
Hard Drive Capacity: 0GBHard Drive Type: Hot-swapHard Drive Type: NoneStorage Controller Type: SATA/SAS
-
43211512
-
Display Technology: None.Video Card: Matrox G200e
-
3 Years
-
3 Years
-
Limited warranty includes replacement and next business day response time.
