Limited Quantity Available
- Call for next available delivery
Brother - 25 years experience in direct thermal technology!
Ordering Information
$618.35
Quick View
Getting Details
Featuring high print resolutions at 300dpi, the TD-4520DN desktop printer lets you print 4-inch barcodes, shipping labels, tags, and more at up to 6 inches per second. Streamline your workflow with the ability to print from multiple PCs on one network, its easy-to-use LED icons replace the LCD display on this affordable, high-resolution printer.
-
4.40 lbs
-
Printer Languages: ZPL II, CPCL
Emulations: Raster Graphics, Text (Template) ESC P
Linear barcodes: Code39, Code93, Code128, ITF, UPC-A/E, EAN8/13, GS1-128 (UCC/EAN-128), GS1 DataBar (RSS), MSI / Plessey, Codabar (NW-7), POSTNET
2D barcodes: PDF417 / MicroPDF417, Data Matrix, Maxicode, QR Code / Micro QR Code, Aztec
Fonts: 6 BMP & 5 Outline fonts
Media type: Brother RD roll or fanfold, die cut or continuous label, continuous receipt, tag and wristband -
Connectivity Technology: WiredConnector: Mini DIN 9-pinConnector: RJ-45Connector: USB Type AConnector: USB Type BConnector Type: EthernetConnector Type: LANConnector Type: SerialConnector Type: Serial (RS-232)Connector Type: USBConnector Type: USB 2.0Printer Output Type: Monochrome
-
Printer, AC adapter, power cord, USB cable, software, documentation
-
Language Simulation: Comtec Printer Control Language (CPCL)Language Simulation: CPCL-nativeLanguage Simulation: EPSON ESC/PLanguage Simulation: EPSON ESC/P RasterLanguage Simulation: Swift Graphic Raster (SGRaster)Language Simulation: ZPL II
-
Color: BlackColor: GrayColor: WhiteForm Factor: ExternalModel: TD-4520DNPrint Technology: Direct thermalPrinter Type: Label printerScanner Type: NoneType: PrinterWarranty Period: 2 yearsWeight Taxonomy: 4.4lbs
-
Media Capacity (Standard): 1rollsStandard Media Size (max): Roll (0.75 in)Standard Media Size (max): Roll (4.65 in)Standard Media Size (max): Roll (5 in)Supported Media Type: Continuous labelsSupported Media Type: Die cut labelsSupported Media Type: Fanfold paperSupported Media Type: Receipt paperSupported Media Type: TagsSupported Media Type: Wristbands
-
RAM (installed): 256MBRAM (max): 256MBRAM Technology: SDRAM
-
Printer Memory: 64 DRAM, 256MB Flash
-
Networking Type: Print server
-
B&W H-Resolution (max): 300dpiB&W Print Speed (max): 6inch/secB&W Resolution (max): 300 dpiB&W Resolution (max): 300 x 300 dpiB&W V-Resolution (max): 300dpi
-
7.1" x 6.1" x 8.8"
-
USB 2.0 Type B port
USB 2.0 Type A port
Mini DIN 9-pin RS232C Serial port
RJ-45 Ethernet LAN 10/100Base-TX port
-
Power Specifications: External AC Adapter (Input: 100 – 240VAC 50/60Hz 2.0A, Output: 24VDC 2.5A)
-
Networking Protocol: 802.1xNetworking Protocol: EAP-FASTNetworking Protocol: EAP-MD5Networking Protocol: EAP-TLSNetworking Protocol: EAP-TTLSNetworking Protocol: PEAP
-
8.4 lbs
-
Windows Server 2016/2012R2/2012/2008R2/2008/2003 Windows 10/8/7, Windows XP, Linux
OS Required: Android 4.0.3 or laterOS Required: Apple iOS 11 or laterOS Required: LinuxOS Required: Microsoft Windows 10OS Required: Microsoft Windows 7OS Required: Microsoft Windows 8OS Required: Microsoft Windows 8.1OS Required: Microsoft Windows Server 2008OS Required: Microsoft Windows Server 2008 R2OS Required: Microsoft Windows Server 2012OS Required: Microsoft Windows Server 2012 R2OS Required: Microsoft Windows Server 2016OS Required: Microsoft Windows Server 2019OS Required: Microsoft Windows Server 2022OS Required: Windows 11OS Required: Windows 8OS Required: Windows 8.1 -
43212100
