Temporarily Out-of-Stock
- Call for next available delivery
Cisco UCS SmartPlays are designed to help lower your TCO. They deliver the exceptional performance, agility, and scale that have made Cisco UCS fast-growing x86 server lines. Whether you're just getting started or expanding your Cisco UCS environment, Cisco UCS SmartPlay bundles provide a fast, easy approach to buying Cisco UCS Servers.
-
195.00 lbs
-
# External 3.5" Bays: 56
-
Server, bezel, (2) CPU heatsinks, rack rail kit, (2) 7mm SSD blank filler, SIOC blanking plate, (4) power supplies, documentation
-
Chassis Form Factor: 4U RackmountChassis Form Factor: Rack-mountableColor: BlackColor: GrayColor: SilverForm Factor: DIMM 288-pinPrinter Type: NoneSystem Type: ServerWeight Taxonomy: 195lbs
-
Environmental properties:
Operating temperature: 41 to 95%
Operating humidity: 10 to 90%, non-condensing -
Cache Memory (installed): 30MBMemory Attributes: Single RankMemory Rating: PC4-19200RAM (installed): 128GBRAM Technology: DDR4 SDRAM
-
128GB (8x16GB) 2400MHz ECC DDR4 SDRAM.
There are sixteen 288-pin DIMM memory slots. Eight slots are occupied by removable 16GB modules; the remaining slots are available.
Video memory: graphics card(s) sold seperately. -
There is no operating system pre-installed.
-
OS Provided: No operating systemOS Provided: No Operating System Installed
-
CD/DVD Type: No Optical DriveCD/DVD Type: None
-
6.9"h x 17.5"w x 32.0"d
-
Expansion slots:
(2) CPU (0 free)
(4) Expansion slots (2 occupied)
Expansion bays:
(4) 2.5" SFF HS bays (2 bays are occupied by 480GB SSD boot drives)
(56) 3.5" LFF HS bays (14 bays are occupied by removable 6TB hard disk drives)
I/O:
(1) USB 3.0 (rear)
(2) RJ-45 LAN (40GbE QSFP+) (rear)
(1) RJ-45 management (rear)
(1) KVM (rear)
(4) Power in
Network controller:
2xQSFP+
Data link protocol: 40GbE, 40Gb FCoE
Storage controller:
Integrated RAID controller, SATA 6Gb/s SAS 12Gb/s, 4GB buffer size. Supports RAID level 0/1/5/6/10/50/60/JBOD.
Storage drives:
2x480GB SATA 6Gb/s 2.5" boot solid state drives
14x6TB SAS 12Gb/s Serial Attached SCSI 7200rpm hot-swappable hard disk drives -
# Power Supplies Installed: 4# Power Supplies Supported: 4Power Provided: 1050Power Provided: 1050W
-
(4) Hot-plug power supplies, 2+2 redundant
Nominal voltage: 120 to 230V AC, 50 to 60Hz
Power provided: 1050W -
# Processors Installed: 2# Processors Supported: 2# Processors Supported: 4Data Bus Speed: 2400MHzNumber of Cores: 12-coreProcessor Features: Intel Turbo Boost TechnologyProcessor Manufacturer: IntelProcessor Model Number: E5-2650V4Processor Speed: 2.2GHzProcessor Speed (Boosted): 2.9GHzProcessor Type: XeonProcessor Upgradability: Upgradable
-
Networking Protocol: 40 Gigabit EthernetNetworking Protocol: 40Gb Fibre Channel over Ethernet (FCoE)Networking Protocol: Gigabit Ethernet
-
Due to manufacturer restrictions, all sales on this item are final.
-
1 lbs
-
Compliant Standards: AS/NZS 60950-1Compliant Standards: AS/NZS CISPR 22:2004 Class ACompliant Standards: AS/NZS CISPR22:2004 Class ACompliant Standards: CAN/CSA C22.2 No. 60950-1Compliant Standards: CAN/CSA-C22.2 No. 60950-1Compliant Standards: CISPR 22 Class ACompliant Standards: CISPR 22 Class BCompliant Standards: CISPR 24Compliant Standards: Directive 2004/108/ECCompliant Standards: Directive 2006/95/ECCompliant Standards: EN 300.386Compliant Standards: EN 300386Compliant Standards: EN 55022 Class ACompliant Standards: EN 55024Compliant Standards: EN 60950-1 Second EditionCompliant Standards: EN 61000-3-2Compliant Standards: EN 61000-3-3Compliant Standards: EN55024Compliant Standards: FCC CFR47 Part 15 ACompliant Standards: ICES-003 Class ACompliant Standards: IEC 60950-1 Second EditionCompliant Standards: KN22 Class ACompliant Standards: KN24Compliant Standards: UL 60950-1 Second EditionCompliant Standards: VCCI Class A
-
Hard Drive Capacity: 480GBHard Drive Capacity: 84TBHard Drive Capacity: 960GBHard Drive Interface: SAS 12.0Gb/sHard Drive Interface: SATA 6.0Gb/sHard Drive Interface: Serial ATAHard Drive Type: Hot-plugHard Drive Type: Internal + Solid State DriveHard Drive Type: NoneHard Drive Type: RemovableSpindle Speed: 7200rpmSpindle Speed: 7200.0rpmStorage Controller RAID Level: JBODStorage Controller RAID Level: RAID 0Storage Controller RAID Level: RAID 1Storage Controller RAID Level: RAID 10Storage Controller RAID Level: RAID 5Storage Controller RAID Level: RAID 50Storage Controller RAID Level: RAID 6Storage Controller RAID Level: RAID 60Storage Controller Type: RAIDStorage Controller Type: SAS 12.0 GbpsStorage Controller Type: SATA 6.0 Gbps
-
43211501
-
Display Technology: None.Video Card: No Graphics Controller
-
